Slots
Page 6-11
Field Description
Entity Type
(continued) ❏
(32) 6-port resilient fiber
❏
(65) 12-port UTP, RJ45 connector
❏
(66) 12-port UTP, RJ45 connector (expand-
able)
❏
(67) 13-port UTP, Telco + module
❏
(68) 24-port TUP, 2xTelco
❏
(69) 6-port fiber, ST connector (expandable)
❏
(70) 6-port fiber, SMA connector (expandable)
❏
(71) 6-port coax (expandable)
❏
(72) 4-port fanout
IEEE 802.5 Mau Module:
❏
(1) 12-port UTP, RJ-45 connector
❏
(2) 12-port STP, RJ-45 connector
IEEE 802.5 Ring Builder:
❏
(1) ring builder, STP rin/rout, RJ-45 connec-
tors
Management Module:
❏
(1) standard management module
❏
(2) enhanced management module
Standard Backplane:
❏
(1) standard backplane
Display Panel:
❏
(1) first release front panel
Fan:
❏
(1) standard fan tray
Power Supply:
❏
(2) standard power supply
Switched Ethernet:
❏
(1) headend unit
❏
(2) expansion unit
HwVersion Read-only field; displays the major and minor revision
level of the entity at this location.
