VLAN
Page 5-12
Viewing Statistics for a VLAN Group
You can view statistics — in table and graph formats — for each of the
configured groups of VLAN on the SuperStack II Switch 1000.
To view statistics for a VLAN group:
1
In the VLAN View Page, select the VLAN group for
which you want to view statistics by clicking once on
its VLAN group button.
The group number button turns green when selected.
2
Open the Statistics menu (if it’s not already opened)
by clicking once on its menu-level indicator.
3
Click once on Graph (to view statistics in graph for-
mat) or Table (to view statistics in table format).
The Statistics Table or Graph Page appears for the
selected VLAN group.
See “Viewing Statistics” on page 4-18 for more informa-
tion on using the Statistics Page.
