Page 3-7
Menus
The menus on the SuperStack II Switch 1000’s Device Page provide
access to the different management options supported by the Personal-
ity Module.
Tables
Some menus contain tables with information that is configurable
directly on-screen from your Web browser while others contain informa-
tion that is read-only.
The tables below describe how to recognize configurable and read-only
fields.
Configurable Information
Read-only Information
Table Columns
Table columns can be resized by placing the mouse pointer on a column
title’s left or right side (until a double arrow appears) and dragging the
column to the left or to the right, as desired.
Buttons
Some menus contain buttons that allow you to edit and/or update the
page’s table.
The table below describes the different buttons that are available and
their functions.
Menu Item Action
Drop-down menus Select from an available option.
White-colored fields Type information.
Menu Item Action
Green- or gray-colored fields None; read-only field.
Button Action
Apply Applies any changes made to the device.
Refresh Updates the page with the latest information.
Modify Modifies a selected entry.
Add Adds an entry into the table.
