EKI-2525M & 2526M User Manual-V2.1-051507 4
1.3 Specification
Communications
Compatibility IEEE 802.3, 802.3u, 802.3x
LAN 10/100Base-TX, 100Base-FX
Transmission Distance Multi-Mode Fiber: 2KM
(50/125 62.5/125 m)
UTP/STP up to 100 meters
Transmission Speed Up to 100 Mbps
Interface
Connectors 4 x RJ-45
1 x SC type 100M fiber (EKI-2525M)
2 x SC type 100M fiber (EKI-2526M)
6-pin removable screw terminal (power &
relay)
LED Indicators Unit: P1, P2, P-Fail
TX port: Link/Active, Duplex/Collision
Power
Current Overload Protection 0.9A@12V
DC
(25 )
Power Consumption EKI-2525M: 4.44 W
EKI-2526M: 6.41 W
Power Input 2 x Unregulated +12 ~ 48 V
DC
Fault Output 1 Relay Output
Mechanism
Dimensions (WxHxD) 37 x 140 x 95 mm
Enclosure IP30, Metal shell with solid mounting kits
Mounting DIN-rail, Wall
Protection
ESD (Ethernet) 4000 V
DC
Surge (EFT for power) 3000 V
DC
Power Reverse Yes
Environment
Operating Temperature -40~75
