I/O Board

M2.5*6

1

86.PEA02.007

Mainboard

M2.5*6

1

86.PEA02.007

Mainboard (Fan)

M2.5*6

1

86.PEA02.007

LCD Module

M2.5*6

3

86.PEA02.007

Fan

M2.5*6

1

86.PEA02.007

Thermal Module

M2.5*6 (spring
tension)

4

86.PEA02.004

Step

Screw

Quantity

Part No.
