Chapter 1 5
Closed Front View
9 Wireless LAN
communication
button/indicator Enables / disables the WLAN function.
Touchpad toggle Turns the internal touchpad on and off.
HDD Indicates when the hard disk drive is
active.
10 Eject button Presses to eject the optical disk from the
drive.
11 Speakers Left and right speakers deliver stereo
audio output.
No. Icon Item Description
1 Battery Indicator Indicates the computer's battery status.
1. Charging: The light shows amber
when the battery is charging.
2. Fully charged: The light shows blue
when in AC mode.
2 5-in-1 card
reader Accepts Secure Digital (SD), MultiMediaCard
(MMC), Memory Stick (MS), Memory Stick
PRO (MS PRO), xDPicture Card (xD).
Note: Push to remove/install the card. Only
one card can operate at any given time.
No. Icon Item Description
