Page 38 | AlliedWare™ OS How To Note: VPNs for Corporate Networks
Headquarters VPN access concentrator's configuration
# System configuration
set system name=HQ
# User configuration
set user securedelay=600
# Add your approved roaming VPN client usernames.
add user=roaming1 pass=roaming1 lo=no telnet=no
add user=roaming2 pass=roaming2 lo=no telnet=no
add user=roaming3 pass=roaming3 lo=no telnet=no
add user=roaming4 pass=roaming4 lo=no telnet=no
# Define a security officer.
add user=secoff pass=<your-secoff-password> priv=securityofficer
lo=yes telnet=yes
# Change the manager privilege user’s password.
set user=manager password=<your-password>
# RADIUS configuration
# If desired, add a RADIUS authentication server for authenticating
# users.
add radius server=<radius-server-address> secret=<secret-key>
# PPP template configuration
# Create a template to use for incoming roaming Windows VPN client
# connections. This defines authentication and associates the IP pool
# of addresses that are allocated to clients.
create ppp template=1
set ppp template=1 bap=off ippool=roaming authentication=chap echo=10
lqr=off
# L2TP configuration
# Configure an L2TP server to accept incoming roaming Windows VPN
# client connections
enable l2tp
enable l2tp server=both
add l2tp ip=1.1.1.1-255.255.255.254 ppptemplate=1 tos=on
# IP configuration
enable ip
add ip int=vlan1 ip=192.168.140.254
# Configure eth0 for connecting to the Internet with a fixed address.
add ip int=eth0 ip=200.200.200.1
add ip rou=0.0.0.0 mask=0.0.0.0 int=eth0 next=200.200.200.254
# Create an IP pool to allocate unique internal payload addresses to
# incoming VPN clients.
create ip pool=roaming ip=192.168.143.1-192.168.143.50
