Electrical Oven Component
Application Chart
kW Voltage Phase Wire
Oven
Assembly
Part No.
Element
Oven Wire
with Crimp Terminal
Terminal Lug
Bus Bar
Part No.
121011
Oven Relay
Qty. kW Part No. Qty. Size Part No. Qty. Part No. Cat. No. Part No.
24 460/480 3Ø 3 or 4 824951 6 4 120009 1 #8 882559 1 121010 2 DPA33 131352
24 416 3Ø 3 or 4 826394 6 4 120009 1 #8 882558 1 121010 1 DPA33 131352
24 240 3Ø 3 883557 6 4 120009 1 #6 882556 1 121010 1 DPA63 131369
24 208 3Ø 3 or 4 824915 6 4 120008 1 #4 882553 1 121010 1 DPA73 131376
20 380 3Ø 3 or 4 826243 6 4 120007 1 #8 882558 1 121010 1 DPA33 131352
20 240 1Ø 2 883559 5 4 120009 1 #4 882552 1 121010 2 DPA93 131358
20 208 1Ø 2 883561 5 4 120008 1 #2 883384 1 121010 2 DPA93 131358
18 460/480 3Ø 3 or 4 883560 6 3 120007 1 #8 882559 1 121010 2 DPA33 131352
18 416 3Ø 3 or 4 826389 6 3 120007 1 #8 882558 1 121010 1 DPA33 131352
18 240 3Ø 3 883562 6 3 120007 1 #8 882558 1 121010 2 DPA43 131357
18 240 1Ø 2 883558 6 3 120007 1 #4 882552 1 121010 2 DPA73 131376
18 208 3Ø 3 or 4 824914 6 3 120006 1 #6 882556 1 121010 2 DPA53 131359
18 208 1Ø 2 883563 6 3 120006 1 #2 883384 1 121010 2 DPA93 131358
15 380 3Ø 3 or 4 826389 6 3 120007 1 #8 882558 1 121010 1 DPA33 131352
