6. Flex the sides of the blue bracket to remove the hard disk drive from the bracket.
7. To install a new hard disk drive into the blue bracket, flex the sides of the bracket and align pin 1 , pin 2 ,
pin 3 , and pin 4 on the bracket with the corresponding holes in the hard disk drive. Do not touch the
circuit board 5 on the bottom of the hard disk drive.
Figure 18. Installing the hard disk drive into the bracket
8. Slide the new hard disk drive into the drive cage until it snaps into position.
Figure 19. Installing the primary hard disk drive
50 ThinkServer TS140 User Guide
