Hardware Maintenance Manual
48
Replacing the speakers system
To replace the speakers system
1. Remove the computer stand. Refer to “Removing the computer stand”.
2. Remove the computer cover. Refer to “Removing the computer cover”.
3. Remove the motherboard cover. Refer to “Removing the motherboard cover”.
4. Disconnect the speakers system cables from the motherboard.
5. Remove the 4 screws that secure the left and right speakers to the chassis.
6. Pull out the left and right speakers from the chassis.
7. Align the new speakers with the chassis, then secure them with the 4
screws.
8. Connect the speakers system cables to the motherboard.
9. Reattach the motherboard cover.
10. Reattach the computer cover and stand.
