Replacing the wlan card – Lenovo C205 All-In-One User Manual
Page 48
Hardware Maintenance Manual
46
Replacing the WLAN card
To replace the WLAN card
1. Remove the computer stand. Refer to “Removing the computer stand”.
2. Remove the computer cover. Refer to “Removing the computer cover”.
3. Remove the motherboard cover. Refer to “Removing the motherboard
cover”.
4. Disconnect the antenna cables from the WLAN card.
5. Remove the 2 screws that secure the WLAN card to the motherboard.
6. Pull the WLAN card upward to remove it from the card port.
7. Align the new WLAN card with the card port, then insert it.
8. Screw the new WLAN card in.
9. Connect the antenna cables to the new WLAN card.
10. Reattach the motherboard cover.
11. Reattach the computer cover and stand.
