Chapter 8. Replacing hardware
39
11. Screw the new optical drive back onto the chassis.
12. Reattach the computer cover and stand.
Replacing the converter board
To replace the converter board
1. Remove the computer stand. Refer to “Removing the computer stand”.
2. Remove the computer cover. Refer to “Removing the computer cover”.
3. Remove the 2 screws that secure the converter board to the chassis.
4. Lift up the converter board and disconnect the power cables from the
converter board.
5. Separate the converter board from the insulating box.
6. Slide the new converter board into the insulating box.
7. Connect the power cables to the new converter board.
8. Align then screw in the new converter board to the chassis.
9. Reattach the computer cover and stand.
