5.

Press

the

cover-release

button

on

the

top

of

the

computer

cover,

slide

the

cover

to

the

rear,

and

remove

it.

If

your

computer

has

screws

to

secure

the

computer

cover,

remove

the

screws,

and

then

remove

the

cover.

Accessing

system

board

components

and

drives

You

might

need

to

remove

the

drive

bay

assembly

to

access

system

board

components

such

as

memory,

the

battery,

and

CMOS.

To

access

system

board

components

and

the

drives:

1.

Remove

the

computer

cover.

See

2.

Remove

the

front

bezel

by

releasing

the

three

tabs

and

pivoting

the

bezel

forward

to

remove

completely.

Figure

5.

Sliding

the

cover

Figure

6.

Removing

the

bezel

10

Hardware

Installation

and

Replacement

Guide
