Lenovo S20-30 / S20-30 Touch Hardware Maintenance Manual

56

Figure 11. LCD panel, LCD cable and hinges (continued)

Disconnect the connector

, lift the LCD panel in the direction shown by arrow

.

When installing:

Make sure that the connector is attached firmly.

Remove six screws

and the hinges in the direction shown by arrows

.

Step

Screw (quantity)

Color

Torque

M2 × 3 mm , flat-head, nylok-coated (6)

Black

1.35 kgfcm

b

c

b

c

a

b

b

a

a

a

b

a

a

a

a
