47
Lenovo IdeaPad U460
Figure 9. Removal steps of keyboard bezel (continued)
Remove the keyboard bezel in the direction shown by arrow
5 .
5
Remove two screws
6 and then remove the speakers in the direction shown
by arrows 7 .
6
6
7
7
Step Screw (quantity) Color Torque
6
M2.5 × (5.7+2) mm, flat-head, nylok-coated (2) Black 2.5 kgfcm
Note: Touch inductive panel is fixed on the keyboard bezel.
