4 Intelligent Diagnostics Module connector 20 Redundant power supply connector 2
5 Front VGA connector 21 Backplane power connector 1
6 SATA connector 0 22 Backplane power connector 2
7 SAS connector 4-7 23 System fan 7 connector
8 SAS connector 0-3 24 Microprocessor socket 2
9 System board battery 25 System fan 6 connector
10 Platform Controller Hub (PCH) 26 Memory slots (6)
11 Internal USB Type A connector 1 27 System fan 5 connector
12 TMM Premium connector 28 System fan 3 connector
13 Internal USB Type A connector 2 29 Microprocessor socket 1
14 TPM connector 30 System fan 2 connector
15 iButton socket 31 Memory slots (6)
16 ThinkServer Management Module 32 System fan 1 connector
1 Front panel connector
Used to connect the front panel cable.
2 Internal USB connector 1
Used to connect the front panel USB cable.
3 Internal USB connector 2
Reserved for the manufacturer.
4 Intelligent Diagnostics Module connector
Used to connect the cable of the Intelligent Diagnostics Module.
5 Front VGA connector
Used to connect the cable of the front VGA connector on the front panel of the server.
6 SATA connector 0
Used to connect the signal cable of the slim optical drive if the server has one installed.
7 SAS connector 4-7
Used to connect the mini-SAS connector on one end of a mini-SAS to mini-SAS signal cable to support the
hard disk drive 4 to hard disk drive 5.
8 SAS connector 0-3
Used to connect the mini-SAS connector on one end of a mini-SAS to mini-SAS signal cable to support the
hard disk drive 0 to hard disk drive 3.
34 ThinkServer RD330 User Guide
