Page 57

53
Lenovo IdeaPad S410p/S410p Touch/S510p/S510p Touch
1110 System board
Important notices for handling the system board:
When handling the system board, bear the following in mind.
• Be careful not to drop the system board on a bench top that has a hard surface,
such as metal, wood, or composite.
• Avoid rough handling of any kind.
• During the whole process, make sure not to drop or stack the system board.
• If you put a system board down, make sure to put it only on a padded surface such
as an ESD mat or conductive corrugated material.
For access, remove these FRUs in order:
• “1010 Battery pack” on page 32
• “1020 Dummy card” on page 33
• “1030 Base cover” on page 34
• “1040 Optical drive” on page 36
• “1050 Hard disk drive” on page 37
• “1060 PCI Express Mini Card for wireless LAN” on page 39
• “1080 Keyboard” on page 42
• “1090 Keyboard bezel” on page 45
• “1100 USB board and ODD board” on page 51
