Lenovo IdeaPad S410p Notebook User Manual
Page 52
48
IdeaPad S410p/S410p Touch/S510p/S510p Touch Hardware
Maintenance Manual
Figure 9. Removal steps of keyboard bezel (continued)
S510p/S510p Touch
Step Screw (quantity)
Color
Torque
5
M2 × 6 mm, flat-head, nylok-coated (2)
KB Support to L-Case
Black
1.85+/-0.15 kgf*cm
5
M2 × 6 mm, flat-head, nylok-coated (4)
KB Support to L-Case
Black
1.85+/-0.15 kgf*cm
