13
Chapter 3
3
Using Your PALMPIX Camera
When you connect the KODAK PALMPIX Camera to your PALM Handheld and
start the PALMPIX Image Capture Application:
m
the PALM Handheld Date Book button becomes the Preview/Shutter
button
m
the PALM Handheld Scroll-up button becomes the Zoom toggle button
m
the PALM Handheld screen becomes the viewfinder
Connecting the Camera
For the camera to work, it must be connected to a PALM m500 Handheld series
that has the PALMPIX Image Capture Application installed. When the camera is
connected, the lens faces away from the back of the PALM Handheld.
1 Flip open the camera.
2 Fit the connector end of the camera over the
PALM Handheld connector and press to seat
the connectors.
3 Push the camera latches forward and fit the
camera tabs into the indents in the PALM
Handheld.
