Axis Communications AXIS T95A10 User Manual
Page 52
Pagina 52
AXIS T95A00 / T95A10 Dome Housing
Per l'unità AXIS T95A00 Dome Housing
Collegare il cavo di alimentazione (100-240 volt CA) all'alloggiamento.
Collegare l'alloggiamento fissando i due cavi forniti al
coperchio e al corpo mediante le viti M3 e la rondella
dentata.
Panoramica dell'installazione
100-240 V CA
Ingresso 100-240 V CA
Uscita 24 V CC
completa
N
L
GND
Uscita 12 V CC
Uscita 230 V CA
Blu
Nero
Ingresso 100-240V CA
