AXIS T95A00 / T95A10 Kuppelgehäuse
Bei AXIS T95A00 Kuppelgehäuse
Schließen Sie das Stromkabel (100–240 V~) an den entsprechenden Klemmen im Gehäuse an.
Erden Sie das Gehäuse, indem Sie die beiden
mitgelieferten Kabel mit den M3 Schrauben und den
Sicherungsscheiben an der Abdeckung und am Gehäuse
befestigen.
Übersicht der
100–240 V~
Eingang 100–240 V~
24 V-Ausgang
(Gleichspannung)
12 V-Ausgang
(Gleichspannung)
Schwarzes
Kabel
Blaues
Kabel
Ausgang 230 V~
N
L
GND
kompletten Installation
Eingang 100-240V~
