Vollrath Cayenne Heated Angled Display Cases - Manual (Page 9)

9
ENGLISH
O
peratOr
’
s
M
anual
sPare Parts list - 48” h
ot
F
ood
m
erchandiser
, m
odel
~ 40735
Callout Part Number Description
1 XFMA7113 ELEMENT, 1500W, 120V
2 XFMA7102 SHELF, LARGE
3 XWMA1004 ROCKER SWITCH, ON/OFF
4 XFMA7004 THERMOSTAT
5 XAA0012 CABLE RESTRAINT
6 XFWW2004 CONTROL KNOB ( ATTACHED TO T-STAT POST)
6 XFMA7008 CONTROL KNOB (VOLLRATH BLUE)
7 XFMA7007 CONTROL KNOB OUTER RING (TEMP GRADUATIONS 85-175)
8 XAA0011 PILOT LIGHT
9 N/A PILOT LIGHT FASCIA
10 XAA0007 BLACK PLASTIC D SHAPE FASCIA
10 XAA0009 BLUE VOLLRATH FASCIA
11 XFMA7011 WATER PAN
12 XFMA7012 SIDE GLASS, 23-1/4" Tall (Anvil Models)
12 XFMA7013 SIDE GLASS, 15-5/8" Tall (Vollrath Models)
13 XFMA7501 GLASS REAR RIGHT, 23-1/4" Tall (Anvil Models)
13 XFMA7541 GLASS REAR RIGHT, 15-1/2" Tall (Vollrath Models)
14 XFMA7504 GLASS REAR LEFT, 23-1/4" Tall (Anvil Models)
14 XFMA7542 GLASS REAR LEFT, 15-1/2" Tall (Vollrath Models)
15 XFMA7401 VERTICAL SHELF SUPPORT (Anvil Models)
15 XFMA7301 VERTICAL SHELF SUPPORT (Vollrath Models)
16 XFMA7017 HORIZONTAL SHELF SUPPORT, RIGHT SIDE
16 XFMA7016 HORIZONTAL SHELF SUPPORT, LEFT SIDE
17 XFMA7507 GLASS FRONT LEFT, 23-5/8" Tall (Anvil Models)
17 XFMA7543 GLASS FRONT LEFT, 15-3/4" Tall (Vollrath Models)
18 XFMA7018 LIGHT BULB
19 XFMA7019 LIGHT BULB CONNECTOR(ANVIL UNITS)
19 XFMA7020 LIGHT BULB CONNECTOR(VOLLRATH UNITS)
20 XFMA7027 PLASTIC LIGHT BULB COVER
21 XAA0008 ANVIL STICK ON BADGE
22 XFFA8011 RUBBER FOOT
23 XFMA7510 GLASS FRONT RIGHT, 23-5/8" Tall (Anvil Models)
23 XFMA7544 GLASS FRONT RIGHT, 15-3/4" Tall (Vollrath Models)
24 XFMA7024 BALLAST, 11 Watts
25 N/A STARTER CONNECTOR BLOCK
26 XFMA7026 STARTER
27 XAA0006 POWER CORD, 120V, WITH NEMA5-15P PLUG
28 XFMA7103 SHELF MEDIUM
29 XFMA7104 SHELF SMALL
30 XFMA7017 HORIZONTAL SHELF SUPPORT, RIGHT SIDE
31 XFMA7515 TOP COVER, GRAY (Anvil Models)
31 XFMA7555 TOP COVER, DARK BROWN (Vollrath Models)
32 XFMA7516 LOWER DOOR TRACK (CUT TO FIT)
XFMA7003 LOCKING BAR
