9

ENGLISH

O

peratOr

’

s

M

anual

sPare Parts list - 4/3 h

eat

‘n s

erve

r

ethermalizer

~ 72109, 72111

and

72112

Callout Part

Number Description

Model

72109

Model

72112

Model

72111

1

17800

WELL, 4/3's PLASTIC, W/DRAIN

1

1

1

2

44138

CONTROL BOX ASSEMBLY, 240V

1

3

44024

BOTTOM COVER

1

1

1

4

44287

HEATER, 120V 800W

2

-

2

44277

HEATER, 240V 800W

-

2

-

5

17847

CORD, POWER, 120V 5-15P

1

5

17860

CORD, POWER, 120V 5-20P

1

5

17739

CORD, POWER, 240V 6-15P

1

6

26543

CORD CONNECTOR

1

1

1

7

44196

DRAIN ADAPTER

1

1

1

8

23424

DRAIN VALVE ASSEMBLY

1

1

1

9

17868

"D" SHAPED HEATER GASKET

2

2

2

10

17950

THERMOSTAT, HIGH LIMIT

2

2

2

11

25438

THERMOSTAT - REGULATING

1

1

1

12

17496

SCREW, #6-32 X .250

6

6

6

13

17014

SCREW, #10-32 X .625

9

9

9

14

17365

O-RING, ADAPTER, DRAIN

1

1

1

15

17018

SCREW, 8-32 X .500

6

6

6

16

17928

UNIVERSAL THERMOSTAT BRACKET

2

2

2

17

17117

SCREW, #10-32 X .25 LG.

2

2

2

18

23686

RIVET, POP - .125 DIA.

4

4

4

19

44005

MOUNTING BRACKET

1

1

1

20

44001

MOUNTING BRACKET W/CUTOUT

1

1

1

21

44179

MOUNTING CLIP

4

4

4

22

23035

1/4-20 x 2" THUMB SCREW

4

4

4

23

17020

SCREW #6-32 x 1/2" PH RD

1

1

1

24

17019

17019 #6-32 KEPS NUT

2

2

2

25

17083

SLEEVING (NOT SHOWN)

1

1

1

26

17428

RATING LABEL - NSF

1

1

1

27

44137

CONTROL BOX ASSEMBLY, 120V

1

1

17972

HARNESS ASSEMBLY (120V)

1

1

17973

HARNESS ASSEMBLY (240V)

1

29292-2

SWITCH KIT, For models made before

March 1999

1

1

1
