7
ENGLISH
O
peratOr
’
s
M
anual
3
1
8
4
5
8
7
11
10
9
7
6
8
4
8
5
10
3
7
11
1
3
3
2
2
16
29
19
25
26
21 23
15
22 24
17
28
27
12
18
exPloded vieW - 4/3 h
eat
‘n s
erve
r
ethermalizer
~ 72050
and
72055
Callout Part
Number Description
1 17755 WELL, 4/3's PLASTIC
2 17868 "D" SHAPED HEATER GASKET
3 44287 HEATER, 120V 800W
4 44459 HI LIMIT PLATE
5 17504 THERMOSTAT, HIGH LIMIT
6 17741 LOOP CLAMP
7 17020 SCREW #6-32 x 1/2" PH RD
8 17019 #6-32 KEPS NUT
9 25438 THERMOSTAT - REGULATING
10 17117 SCREW 10-32 x 1/4" PHILLIPS
11 17014 SCREW, #10-32 X .625 THREAD ROLLING
12 44293 PANEL, SIDE
13 44297 PANEL, BACK
14 44295 PANEL, FRONT
15 23095 Rivet, Pop - .125 Dia.
16 17074 THERMOSTAT, SHORT CAPILLARY
Callout Part
Number Description
17 17686 SCREW, M4-0.7 X 5MM
18 1755901 PILOT LIGHT, BLUE - 120V
19 17388 KNOB, CONTROL
20 17848 HARNESS, WIRE (NOT SHOWN)
21 44292 PANEL, BOTTOM
22 17416 LEG, PHENOLIC (BLACK)
23 17018 SCREW, 8-32 X .500
24 21775 #8-32 TRUSS HEAD .500 LG.
25 17023 CORD, POWER, 120V 5-15P
25 17860 CORD, POWER, 120V 5-20P (Canada Only)
26 17872 90 DEG STRAIN RELIEF
27 23989 CLAMP, LOOP, 3/8 DIA X 1/2
28 17559 PILOT LIGHT, RED - 120V
29 2325401 SWITCH, ROCKER, 125V
29292-2
SWITCH KIT, For models made before March
1999
sPar Parts list - 4/3 h
eat
‘n s
erve
r
ethermalizer
~ 72050
and
72055
