Revolabs Quick Start Guide

Revolabs Inc • 63 Great Road, Maynard, MA 01754 • 1-800-326-1088 • www.revolabs.com • [email protected]

Using a Solo

Wearable Wireless Microphone

You are now ready to experience wireless, rechargeable and

secure (encrypted) collaborative freedom.

With the microphone in the wearing position, un-mute the
microphone by pressing and releasing the MUTE button (confirm by
viewing flashing GREEN LED).

Step

#

3

Mute/un-mute toggle button

Flashing red = muted

Flashing green = un-muted

Q

S

G

-W

M

-v

1.

0-

20

07

Remove the microphone from the Charger Base. The microphones
turn on and mute themselves automatically when removed from
Charger Base (flashing RED LED) to prevent handling noise while
attaching the microphone.

Step

#

1

The wireless microphone has a clip on the back allowing the
microphone to be easily clipped onto a shirt pocket, blouse or lapel.
The microphone can also be clipped to a lanyard and worn around
the neck. Attach the microphone to clothing or a lanyard, as close to
the mouth as possible (within 6 - 12 inches is recommended).
Shorten the lanyard by tying a knot in the material, if necessary.

Step

#

2

* make sure top is pointed toward mouth

To turn microphones off, first mute the microphone, and then plug
it into the Charger Base. Make sure the RED LED turns on.
Optionally, the microphone can be turned off manually. Simply press
and hold the MUTE button for ~10 seconds until the LED turns solid
RED and release button.

Step

#

4
