1-8 Issue 2 December 1995
Introduction and Requirements for Integration
Switch Integration Device Required Hardware
Table 1-1 lists the required SID components for the integration.
NOTE:
AT&T only assumes responsibility for connecting the Null cable and the
Y-cable to the SID. All remaining connections must be performed by the
customer or the customer’s switch technician.
Table 1-2. Switch Integration Device Hardware Components Required for the
Integration
Component Description
AT&T
Supplied
Customer
Supplied
SID AT&T Switch Integration Device,
Release 2 X
Null Cable Used for connection to SID X
Y-Cable Used for connection from Null cable to
customer A25B Cable X
A25B Cable 25-pair Amphenol female-to-female cable
used to connect Y-Cable and NEAX port
cable or MCI cable X
MCI Cable Cable that connects from the NEAX MCI
digital port to the A25B cable X
