Issue 2 December 1995 A-5
Error Logs
Error Logs
The SID accumulates and records or logs error messages. The error messages
can help solve problems and trace errors. You can access the error logs on the
SID if you are authorized to use security level 1 features.
The error logs also are available to trained support personnel to assist with
troubleshooting. Use the instructions in this section to log on to the SID and view
the error logs.
1. Press to access the MAIN MENU as shown in the following
example:
2. Press to select Logs. After you press the key, you see the LOGS menu
as shown in the following example:
0
3. Press to view the error logs. After you press the key, you see the an
error log screen similar to the following example:
0
NOTE:
Your error log screens may appear different than the screen shown in the
example.
NEC 1-View 2-Utils 3-System
4-Setup 5-Logs
LOGS 1-View 2-Purge
ER_LOG 16-Bad PBX Pkts > 5%000000000000000I
01/12 12:34 01/16 23:14000000000056
FUNC
