Hardware Setup
CPLD Data Reflash Pinheader:JP1
This connector is used to reflash the CPLD data.
JP1
1 8
Pin Description Pin Description
1 VCC 2 TDD
3 TDI 4 IspEN
5 TRST 6 TMS
7 GND 8 TCK
Pin Definition
Keyboard/Mouse Connector: J3
This connector is used to connect a mouse/keyboard.
PIN SIGNAL
1 KBMS_Power
2 KBMS_Power
3 KEY
4 NC
5 GND
6 GND
7 MSCLK
8 KBCLK
9 MSDAT
10 KBDAT
Pin Definition
J3
1
9
2
10
