MSI 3200 Network User Manual
Page 27
2-11
Hardware Setup
LAN Bypass Definition
Bypass setting in BIOS
Power
Status
BIOS Bypass Setting
Bypass Behavior
Disable
A
On
Bypass mode after power on
Enable
B
Disable
A
Off
Bypass mode after power off
(All segment or by each segment are controllable)
Enable
B
Pass Through Behavior: A
Bypass Behavior: B
