2
MS-7788
CPuFAN, SySFAN, SySFAN2: Fan Power Connectors
the fan power connectors support system cooling fans with +2V. if the main-
board has a System Hardware Monitor chipset on-board, you must use a specially
designed fan with a speed sensor to take advantage of the CPu fan control. re-
member to connect all system fans. Some system fans may not connect to the
mainboard and will instead connect to the power supply directly. A system fan can
be plugged into any available system fan connector.
1.Gro
und
2.+1
2V
3.Se
nsor
4.Co
ntrol
CPuFAN SySFAN
1.Gro
und
2.+1
2V
3.Se
nsor
4.No
Use
SySFAN2
1.Gro
und
2.+1
2V
3.No
Use
SAtA~4: Serial AtA Connector
this connector is a high-speed Serial AtA interface port. each connector can con-
nect to one Serial AtA device. Serial AtA devices include disk drives (Hdd), solid
state drives (SSd), and optical drives (Cd/ dVd/ Blu-ray).
iMPortANt
Please do not fold the Serial AtA cable at a 90-degree angle. data loss may
result during transmission otherwise.
SAtA cables have identical plugs on either sides of the cable. However, it is
recommended that the flat connector be connected to the mainboard for space
saving purposes.
*
*
