2-18
Hardware Setup
▍
MS-7593 Hardware Setup
▍
MS-7593
Front USB Connector: JUSB1 / JUSB2 / JUSB3
Ths connector, complant wth Intel ® I/O Connectvty Desgn Gude, s deal for con-
nectng hgh-speed USB nterface perpherals such as USB HDD, dgtal cameras, MP3
players, prnters, modems and the lke.
USB 2.0 Bracket (optonal)
1.VC
C
3.US
BD-
10.U
SBO
C
5.US
BD+
7.Gro
und
9.No
Pin
8.Gro
und
6.US
BD+
4.US
BD-
2.VC
C
Important
Note that the pns of VCC and GND must be connected correctly to avod possble
damage.
Seral Connector: JCOM1
Ths connector s a 16550A hgh speed communcaton port that sends/ receves 16
bytes FIFOs. You can attach a seral devce.
1.DC
D
3.SO
UT
10.N
o Pin
5.Gro
und
7.RT
S
9.RI
8.CT
S
6.DS
R
4.DT
R
2.SIN
