MSI X58M - Manual (Page 13)

Gettng Started
▍
MS-7593
1-3
Gettng Started
▍
MS-7593
RAID
SATA1~6 support Intel ® Matrx Storage Technology (AHCI/ RAID 0/ 1/ 5/ 10) by
ICH10R
Floppy
1 floppy port
Supports 1 FDD wth 360 KB, 720 KB, 1.2 MB, 1.44 MB and 2.88 MB
Connectors
Back panel
1 PS/2 keyboard port
1 PS/2 mouse port
6 USB 2.0 ports
1 E-SATA port
1 IEEE 1394 port (optonal)
1 LAN port
6 flexble audo ports
On-Board
3 USB 2.0 connectors
1 IEEE 1394 connector (optonal)
1 Chasss Intruson connector
1 Seral connector
1 CD-In connector
1 Front Panel Audo connector
1 TPM Module connector (optonal)
1 Hardware Overclock Base clock swtch
1 Power button
1 S/PDIF-Out connector
Slots
2 PCI Express 2.0 x16 slots
1 PCI Express 2.0 x4 slot
1 PCI slot, support 3.3V/ 5V PCI bus Interface
Form Factor
Mcro-ATX (24.5cm X 24.5 cm)
Mountng
8 mountng holes
■
■
■
■
-
-
-
-
-
-
-
■
-
-
-
-
-
-
-
-
-
-
■
■
■
■
■
