2-16
Hardware Setup
▍
MS-7593 Hardware Setup
▍
MS-7593
Fan Power Connectors: CPUFAN1,SYSFAN1,SYSFAN2,SYSFAN3
The fan power connectors support system coolng fan wth +12V. When connectng the
wre to the connectors, always note that the red wre s the postve and should be con-
nected to the +12V; the black wre s Ground and should be connected to GND. If the
manboard has a System Hardware Montor chpset on-board, you must use a specally
desgned fan wth speed sensor to take advantage of the CPU fan control.
1.Gro
und
2.+1
2V
3.Se
nsor
4.Co
ntrol
1.Gro
und
2.+1
2V
3.Se
nsor
CPUFAN SYSFAN1/ 2/ 3
Important
Please refer to the recommended CPU fans at processor’s offical webste or consult
the vendors for proper CPU coolng fan.
CPUFAN & SYSFAN1 support Smart fan control. You can nstall Overclockng Center
utlty that wll automatcally control the CPUFAN & SYSFAN1 speeds accordng to
the actual CPUFAN & SYSFAN1 temperatures.
Fan cooler set wth 3 or 4 pns power connector are both avalable for CPUFAN.
CD-In Connector: JCD1
Ths connector s provded for external audo nput.
4.R
3.Gro
und
2.Gro
und
1.L
•
•
•
