2-12
Hardware Setup
▍
MS-7593 Hardware Setup
▍
MS-7593
b
ack
p
aneL
Mouse/Keyboard
The standard PS/2 ® mouse/keyboard DIN connector s for a PS/2 ® mouse/keyboard.
VGA Port
USB Port
The USB (Unversal Seral Bus) port s for attachng USB devces such as keyboard,
mouse, or other USB-compatble devces.
E-SATA Port
The E-SATA (External-SATA) port s for attachng the E-SATA hard drve.
1394 Port (optonal)
The IEEE1394 port on the back panel provdes connecton to IEEE1394 devces.
LAN
The standard RJ-45 LAN jack s for connecton to
the Local Area Network (LAN). You can connect a
network cable to t.
LED Color LED State Condton
Left Yellow Off LAN lnk s establshed.
On(Steady state) LAN lnk s establshed.
On(brghter & pulsng) The computer s communcatng wth another computer on the LAN.
Rght Green Off 10 Mbts/sec data rate s selected.
On 100 Mbts/sec data rate s selected.
Orange On 1000 Mbts/sec data rate s selected.
▶
▶
▶
▶
▶
Mouse
(optonal)
1394 Port
USB Port
LAN
Lne-In
Lne-Out
Mc
RS-Out
CS-Out
SS-Out USB Port E-SATA Port USB Port
Yellow Green/ Orange
Keyboard
