English
13
Internal
Connectors
■ 1x 24-pin ATX main power connector
■ 1x 4-pin ATX 12V power connector
■ 2x SATA 6Gb/s connectors
■ 2x SATA 3Gb/s connectors
■ 2x USB 2.0 connector (supports additional 4 USB 2.0 ports)
■ 1x USB 3.0 connector (supports additional 2 USB 3.0 ports)
■ 1x 4-pin CPU fan connector
■ 1x 4-pin system fan connector
■ 1x 3-pin system fan connector
■ 1x Clear CMOS jumper
■ 1x Chassis Intrusion connector
■ 1x Front panel audio connector
■ 1x Parallel port connector
■ 2x System panel connectors
■ 1x Serial port connector
■ 1x TPM module connector
I/O
Controller
■ NUVOTON NCT6792 Controller Chip
Hardware
Monitor
■ CPU/System temperature detection
■ CPU/System fan speed detection
■ CPU/System fan speed control
BIOS
Features
■ 64 Mb flash
■ UEFI AMI BIOS
■ ACPI 5.0, PnP 1.0a, SM BIOS 2.7, DMI 2.0
■ Multi-language
Form
Factor
■ Micro-ATX Form Factor
■ 9.6 in. x 8.8 in. (24.4 cm x 22.4 cm)
For the latest information about CPU, please visit
http://www.msi.com/cpu-support/
For more information on compatible components, please visit
http://www.msi.com/test-report/
