Cirrus Logic CDB5343 User Manual
Cdb5343, Features, Description
Copyright
© Cirrus Logic, Inc. 2006
(All Rights Reserved)
CDB5343: Evaluation Board for CS5343
Features
Demonstrates Recommended Layout and
Grounding Arrangements
CS8406 Generates S/PDIF and EIAJ-340-
Compatible Digital Audio
Requires Only an Analog Signal Source
and Power Supply for a Complete Analog-
to-Digital Converter System
Description
The CDB5343 evaluation board is an excellent
means for quickly evaluating the CS5343 24-
bit, stereo A/D converter. Evaluation requires
a digital signal analyzer, an analog source,
and a power supply.
Also included is an CS8406 digital audio inter-
face transmitter that generates S/PDIF and
EIAJ-340-compatible audio data. The digital
audio data is available via RCA phone and op-
tical connectors.
AUGUST '06
DS687DB2
CDB5343
S/PDIF
OUTPUT
I/O FOR
CLOCKS
AND DATA
ANALOG
INPUT
CS5343
98 dB, 96 kHz, Audio A/D
Converter
CS8406
AES/EBU
S/PDIF
TRANSMITTER
Document Outline
- 1. System Overview
- 2. CS8406 Digital Audio Transmitter
- 3. Crystal Oscillator
- 4. Clock & Data I/O Header
- 5. Power
- 6. Grounding and Power Supply Decoupling
- 7. Analog Input
- 8. Connectors
- 9. Jumper and Switch Settings
- 10. Reset
- 11. Evaluating the CS5344
- 12. Performance Plots
- Figure 1. FFT (-1 dB 48 kHz)
- Figure 2. FFT (-60 dB, 48 kHz)
- Figure 3. FFT (48 kHz, No Input)
- Figure 4. 48 kHz, THD+N vs. Input Freq
- Figure 5. 48 kHz, THD+N vs. Level
- Figure 6. 48 kHz, Fade-to-Noise Linearity
- Figure 7. 48 kHz, Frequency Response
- Figure 8. 48 kHz, Crosstalk
- Figure 9. FFT (-1 dB 96 kHz)
- Figure 10. FFT (-60 dB, 96 kHz)
- Figure 11. FFT (96 kHz, No Input)
- Figure 12. 96 kHz, THD+N vs. Input Freq
- Figure 13. 96 kHz, THD+N vs. Level
- Figure 14. 96 kHz, Fade-to-Noise Linearity
- Figure 15. 96 kHz, Frequency Response
- Figure 16. 96 kHz, Crosstalk
- 13. CDB Performance Curves
- 14. CDB Schematics
- 15. CDB Layout
- 16. Revision History
