CRD44800-ST-FB
22
5. BILL OF MATERIALS
Line Item
Cirrus P/N
Rev
Description
Qty
U/M
Reference Designator
MFG
MFG. P/N
1
001-01790-01
A
CAP 1000pF ±10% 50V X7R 0603
2
1
EA
C3 C5 C19 C28 C29 C58 C59 C60 C61 C85 C86 C87 C88 C112 C113 C114 C115 C139 C140 C141 C142
PANASONIC
ECJ1VB1H102K
2
001-07078-01
A
CAP 1uF ±10% 25V X7R 1206
9
EA
C14 C40 C44 C68 C71 C95 C98 C122 C125
PANASONIC
ECJ3YB1E105K
3
001-10097-01
A
CAP 120pF ±5% 50V C0G 0603
2
EA
C8 C9
KEMET
C0603C121J5GAC
4
001-01865-01
A
CAP 2200pF ±10% 50V X7R 0603
1
EA
C10
KEMET
C0603C222K5RAC
5
012-00035-01
A
CAP 22uF ±20% 6.3V ELEC RAD
5
EA
C1 C4 C6 C32 C33
PANASONIC
ECEA0JKS220
6
001-03379-01
A
CAP 330pF ±5% 50V C0G 0805
8
EA
C46 C47 C73 C74 C100 C101 C127 C128
KEMET
C0805C331J5GAC
7
001-10043-01
A
CAP 39pF ±5% 50V C0G 0603
2
EA
C11 C30
KEMET
C0603C390J5GAC
8
011-00007-01
A
CAP 0.47uF ±10% 63V MTL FLM RAD
8
EA
C56 C57 C83 C84 C110 C111 C137 C138
BC COMPONENTS
2222 370 11474
9
012-00071-01
A
CAP 470uF ±20% 35V ELEC RAD
4
EA
C41 C69 C96 C123
PANASONIC
ECA1VM471B
10
012-00064-01
A
CAP 47uF ±20% 16V ELEC RAD 6.3x11MM
2
EA
C12 C16
PANASONIC
ECEA1CKS470
11
001-02189-01
A
CAP 0.1uF ±10% 16V X7R 0603
31
EA
C2 C7 C18 C20 C22 C23 C24 C25 C26 C27 C34 C35 C36 C37 C38 C43 C62 C63 C64 C65 C66 C89 C90 C91 C92 C93 C116 C117 C118 C119 C120
KEMET
C0603C104K4RAC
12
001-04345-01
A
CAP 0.1uF ±10% 50V X7R 0805
45
EA
C13 C15 C17 C21 C31 C39 C42 C48 C49 C50 C51 C52 C53 C54 C55 C67 C70 C75 C76 C77 C78 C79 C80 C81 C82 C94 C97 C102 C103 C104 C105 C106 C107 C108 C109 C121 C124 C129 C130 C131 C132 C133 C134 C135 C136
KEMET
C0805C104K5RAC
13
311-00001-01
A
HEATSINK, 30W, APOGEE PWM
1
EA
HS1
SUMMIT HEAT SINKS CO LTD
311-00001-01
14
110-00078-01
A
CONN, FLEX 22PIN, ST, I mm PITCH
1
EA
J2
HIROSE ELECTRIC
FH21-22S-1DSA
15
110-00091-01
A
CONN, 8PIN EH 2.5MM PTCH PWR HDR
1
EA
J12
JST
B8B-EH-A
16
110-00094-01
A
CONN, 2x2 SPKR TERMINAL
1
EA
J5
DRAGON CITY INDUSTRIES
PT-422-03
17
110-00095-01
A
CONN, 6x2 SPKR TERMINAL
1
EA
J4
DRAGON CITY INDUSTRIES
PT-1222P-03
18
040-00022-01
A
IND 22uH 3.5A ±10% 400 DIA TH
16
EA
L5 L6 L7 L8 L9 L10 L11 L12 L13 L14 L15 L16 L17 L18 L19 L20
TRANSTEK MAGNETICS
TMP50612CT
19
020-00788-01
A
RES 10 OHM 1/16W ±1% 0603 FILM
1
EA
R71
DALE
CRCW060310R0F
20
020-00789-01
A
RES 10.2 OHM 1/16W ±1% 0603 FILM
1
EA
R56
DALE
CRCW060310R2F
21
020-00902-01
A
RES 100 OHM 1/16W ±1% 0603 FILM
17
EA
R58 R75 R85 R86 R87 R88 R89 R108 R110 R111 R112 R113 R114 R115 R116 R117 R118
DALE
CRCW06031000F
22
020-01130-01
A
RES 10k OHM 1/16W ±1% 0603 FILM
10
EA
R4 R5 R9 R16 R23 R30 R37 R38 R65 R109
PANASONIC
ERJ3EKF1002V
23
020-00911-01
A
RES 121 OHM 1/16W ±1% 0603 FILM
3
EA
R7 R8 R45
DALE
CRCW06031210F
24
020-01047-01
A
RES 1.96k OHM 1/16W ±1% 0603 FILM
1
EA
R48
DALE
CRCW06031961F
25
020-00934-01
A
RES 200 OHM 1/16W ±1% 0603 FILM
1
EA
R6
DALE
CRCW06032000F
26
020-01048-01
A
RES 2k OHM 1/16W ±1% 0603 FILM
2
EA
R54 R55
DALE
CRCW06032001F
27
021-00718-01
A
RES 20 OHM 1/4W ±5% 1210 FILM
8
EA
R10 R11 R17 R18 R24 R25 R31 R32
DALE
CRCW1210200J
28
020-01181-01
A
RES 29.4k OHM 1/16W ±1% 0603 FILM
1
EA
R49
DALE
CRCW06032942F
29
DELETED LINE ITEM
30
020-00867-01
A
RES 49.9 OHM 1/16W ±1% 0603 FILM
4
EA
R1 R2 R47 R50
DALE
CRCW060349R9F
31
020-01209-01
A
RES 49.9k OHM 1/16W ±1% 0603 FILM
1
EA
R57
DALE
CRCW06034992F
