CS4392
36
DS459PP3
DC ELECTRICAL CHARACTERISTICS
(AGND = 0V; all voltages with respect to AGND.)
Notes: 10. Normal operation is defined as RST = HI with a 997 Hz, 0dBFS input sampled at F
s
= 48kHz, and open
outputs, unless otherwise stated.
11. Power-Down Mode is defined as RST = LO with all clocks and data lines held static.
12. Valid with the recommended capacitor values on FILT+ and VQ as shown in Figures 1 and 2.
DIGITAL INPUT CHARACTERISTICS & SPECIFICATIONS
(AGND = 0V; all voltages
with respect to AGND.)
THERMAL CHARACTERISTICS AND SPECIFICATIONS
Parameter
Symbol
Min
Typ
Max
Units
Normal Operation
(Note 10)
Power Supply Current
All Supplies=5.0V
I
A
+ I
L
-
26
30
mA
Power Dissipation
-
130
150
mW
Power-Down Mode
Power Supply Current
All Supplies=5.0V
I
A
+ I
L
-
300
-
µA
Power Dissipation
-
1.5
-
mW
All Modes of Operation
Power Supply Rejection Ratio
(Note 12)
(1 kHz)
(60 Hz)
PSRR
-
-
60
40
-
-
dB
dB
Common Mode Voltage
Output Impedance
Maximum allowable DC current source/sink
CMOUT
-
-
-
0.48•VA
250
0.001
-
-
-
V
k
Ω
mA
Filt+ Nominal Voltage
Output Impedance
Maximum allowable DC current source/sink
-
-
-
VA
250
0.001
-
-
-
V
k
Ω
mA
MUTEC Low-Level Output Voltage
-
0
-
V
MUTEC High-Level Output Voltage
-
VA
-
V
Maximum MUTEC Drive Current
-
3
-
mA
Parameters
Symbol Min Typ
Max
Units
Input Leakage Current
I
in
-
-
±10
µA
Input Capacitance
-
8
-
pF
High-Level Input Voltage
V
IH
70%
-
-
VL
Low-Level Input Voltage
V
IL
-
20%
VL
Parameters
Symbol Min Typ
Max
Units
Package Thermal Resistance
CS4392-KS
CS4392-KZ/KZZ
θ
JA
θ
JA
-
-
68
72
-
-
°C/Watt
°C/Watt
Ambient Operating Temperature
(Power Applied)
T
A
-10
-
+70
°C
