1

Copyright

©

Cirrus Logic, Inc. 2004

(All Rights Reserved)

http://www.cirrus.com

CDB4351

Evaluation Board for CS4351

Features

Demonstrates recommended layout and
grounding arrangements.

CS8416 receives S/PDIF, & EIAJ-340-
compatible digital audio.

Headers for External PCM Audio and Control
Input

Requires only a digital signal source and
power supplies for a complete Digital-to-
Analog Converter system.

Description

The CDB4351 evaluation board is an excellent means
for quickly evaluating the CS4351 24-bit, high perfor-
mance stereo D/A converter. Evaluation requires an
analog signal analyzer, a digital signal source, a PC for
controlling the CS4351 (stand alone operation is also
available) and a power supply. Analog line-level outputs
are provided via RCA phono jacks.

The CS8416 digital audio receiver IC. provides the sys-
tem timing necessary to operate the Digital-to-Analog
converter and will accept S/PDIF, and EIAJ-340-compat-
ible audio data. The evaluation board may also be
configured to accept external timing and data signals for
operation in a user application during system
development.

ORDERING INFORMATION

CDB4351 Evaluation Board

CS4351

Analog Outputs

and Muting

Control

Port

Inputs for Clocks

and D ata

C S8416

Digital Audio

Interface

OCT ‘04

DS566DB3
