CS4340A
DS590F2 11
4. CHARACTERISTICS AND SPECIFICATIONS
(Min/Max performance characteristics and specifications are guaranteed over the Specified Operating Conditions.
Typical performance characteristics are derived from measurements taken at T
A
= 25 °C.)
RECOMMENDED OPERATING SPECIFICATION
ABSOLUTE MAXIMUM RATINGS
(AGND = 0 V; all voltages with respect to AGND. Operation
beyond these limits may result in permanent damage to the device. Normal operation is not guaranteed at these
extremes.)
1.Any pin except supplies.
Parameters Symbol Min Typ Max Units
DC Power Supply
3.3 V Nominal
5.0 V Nominal VA 3.0
4.5 3.3
5
3.6
5.5 V
V
Ambient Operating Temperature (Power Applied) T
A
-10 - +70
°C
Parameters Symbol Min Max Units
DC Power Supply VA -0.3 6.0 V
Input Current (Note 1) I
in
- ±10 mA
Digital Input Voltage V
IND
-0.3 VA+0.4 V
Ambient Operating Temperature (power applied) T
A
-55 125 °C
Storage Temperature T
stg
-65 150 °C
