CS4340
16 DS297F3
4. APPLICATIONS
4.1 Sample Rate Range/Operational Mode
The device operates in one of two operational modes determined by the Master Clock to Left/Right Clock ratio (see
section 4.2). Sample rates outside the specified range for each mode are not supported.
4.2 System Clocking
The device requires external generation of the master (MCLK) and left/right (LRCK) clocks. The device also requires
external generation of the serial clock (SCLK) if the internal serial clock is not used. The LRCK, defined also as the
input sample rate Fs, must be synchronously derived from MCLK according to specified ratios. The specified ratios
of MCLK to LRCK, along with several standard audio sample rates and the required MCLK frequency, are illustrated
in Tables 2 and 3.
4.2.1 Internal Serial Clock Mode
The device will enter the Internal Serial Clock Mode if no low to high transitions are detected on the SCLK pin
for 2 consecutive periods of LRCK. In this mode, the SCLK is internally derived and synchronous with MCLK
and LRCK. The SCLK/LRCK ratio is either 32, 48, or 64 depending upon the MCLK/LRCK ratio and the Digital
Interface Format selection (see Table 4).
Input Sample Rate (Fs) MODE
4 kHz - 50 kHz Single-Speed Mode
50 kHz - 100 kHz Double-Speed Mode
Table 1. CS4340 Speed Modes
Sample Rate
(kHz)
MCLK (MHz)
256x 384x 512x
32 8.1920 12.2880 16.3840
44.1 11.2896 16.9344 22.5792
48 12.2880 18.4320 24.5760
Table 2. Single-Speed Mode Standard Frequencies
Sample Rate
(kHz)
MCLK (MHz)
128x 192x
64 8.1920 12.2880
88.2 11.2896 16.9344
96 12.2880 18.4320
Table 3. Double-Speed Mode Standard Frequencies
