6. BILL OF MATERIALS
PRINTED CIRCUIT BOARD ASSEMBLY
Item Quantity
Reference
Description
Manufacturer
Manufacturer PN
1
9
C1,C2,C9,C14,C25,C26,C31.
CAP, 0805, COG, 100pF, 5%, 50V.
KEMET.
C0805C101J5GAC.
C32,C36. .
.
.
2
4
C3,C4,C5,C6.
CAP, SMT A, ELEC, 2.2uF, 20%, 35V.
PANASONIC.
ECE-V1VS2R2SR.
3
1
C7.
CAP, 0805, X7R, .022uF, 10%, 50V.
KEMET.
C0805C223K5RAC.
4
5
C8,C12,C37,C38,C41.
CAP, 0805, X7R, .1uF, 10%, 50V.
KEMET.
C0805C104K5RAC.
5
1
C11.
CAP, SMT A, ELEC, 4.7uF, 20%, 25V.
PANASONIC.
ECE-V1ES4R7SR.
6
8
C13,C23,C24,C29,C30,C35.
CAP, SMT B, ELEC, 10uF, 20%, 16V.
PANASONIC.
ECE-V1CA100R.
C42,C43. .
.
.
7
4
C21,C22,C27,C28.
CAP, 0805, C0G, 22pF, 10%, 50V.
KEMET.
C0805C220K5GAC.
8
1
JP1.
HDR, 3x1, 0.025" PIN, 0.1" CTR.
SAMTEC.
TSW-103-07-T-S.
9
1
J1.
CONN, 1/8" DOUBLE SW. STEREO PHONE JACK.
LZR ELECTRON-
ICS.
SJ372.
10
1
J2.
HDR, 4X1, 0.025" PIN, 0.1" CTR, 15u" AU.
MOLEX.
70553-0003.
11
1
J3.
CONN, 1/8" SINGLE SW. STEREO PHONE JACK.
LZR ELECTRON-
ICS.
SJ374.
12
1
J14.
CONN, 7x2 RIBBON, MALE, STRAIGHT, SHROUDED.
AMP.
103309-2.
13
2
J21,J22.
CONN, 1/8" NON-SW. STEREO PHONE JACK.
LZR ELECTRON-
ICS.
SJ373.
14
3
L1,L2,L3.
IND, FBEAD, 1206, 31@100MHz, 25%.
TDK.
HF50ACB321611-T.
15
1
P1.
PCI BUS 5V SIDE B.
.
.
16
1
P2.
PCI BUS 5V SIDE A.
.
.
17
4
R1,R2,R3,R4.
RES, SO, 0805, 6.8K, 1%, 1/10W, METAL FILM.
PHILIPS.
9C08052A6801F.
18
1
R11.
RES, SO, 0805, 1.5K, 1%, 1/10W, METAL FILM.
PHILIPS.
9C08052A1501F.
19
2
R37,R12.
RES, SO, 0805, 2.2K, 1%, 1/10W, METAL FILM.
PHILIPS.
9C08052A2201F.
20
4
R21,R22,R27,R28.
RES, SO, 0805, 27K, 1%, 1/10W, METAL FILM.
PHILIPS.
9C08052A2702F.
21
4
R23,R24,R29,R30.
RES, SO, 0805, 33K, 1%, 1/10W, METAL FILM.
PHILIPS.
9C08052A3302F.
22
4
R25,R26,R31,R32.
RES, SO, 0805, 220K, 5%, 1/10W, METAL FILM.
PHILIPS.
9C08052A2203J.
23
2
R36,R35.
RES, SO, 0805, 10K, 1%, 1/10W, METAL FILM.
PHILIPS.
9C08052A1002F.
24
5
R41,R42,R43,R44,R5.
RES, SO, 0805,100, 1%, 1/10W, METAL FILM.
PHILIPS.
9C08052A1000F.
25
3
U1,U2,U3.
IC, CS5331A, 18-BIT ADC.
CIRRUS LOGIC.
CS5331A-KS.
26
2
U5,U4.
IC, SO, SOIC8, 34072, SINGLE SUPPLY DUAL OP AMP. MOTOROLA.
MC34072D.
27
2
U6,U7.
IC, SO, SOIC8, CS4334, DAC, STEREO.
CIRRUS LOGIC.
CS4334-KS.
28
1
U8.
IC, SO, +5V REGULATOR, MC78M05C, DPAK, 4%,
500mA.
MOTOROLA. MC78M05CDT.
29
1
U9.
IC, 74HC244.
MOTOROLA.
MC74HC244ADW.
