CS35L00
8
DS906PP1
4. CHARACTERISTICS & SPECIFICATIONS
Test Conditions (unless otherwise specified): GND = 0 V; All voltages with respect to ground; Input signal = 997 Hz
differential sine wave; T
A
= 25°C; VBATT = 5.0 V; R
L
= 8
Ω; 22 Hz to 20 kHz measurement bandwidth; Measure-
ments taken with AES17 measurement filter and Audio Precision AUX-0025 passive filter.
RECOMMENDED OPERATING CONDITIONS
GND = 0 V; All voltages with respect to ground. Please see
.
ABSOLUTE MAXIMUM RATINGS
GND = 0 V; All voltages with respect to ground.
WARNING:
Operation at or beyond these limits may result in permanent damage to the device.
Notes:
4. Functionality is not guaranteed or implied outside of these limits. Operation outside of these limits may
adversely affect device reliability.
5. No external loads should be connected to the LFILT+ net. Any connection of a load to this point may
result in errant operation or performance degradation in the device.
Parameters
Symbol Min Typ
Max
Units
DC Power Supply
Supply Voltage
VBATT
2.5
5.0
5.5
V
Temperature
Ambient Temperature
T
A
-10
-
+70
°C
Junction Temperature
T
J
-10
-
+150
°C
Parameters
Symbol
Min
Max
Units
DC Power Supply
Supply Voltage
VBATT
-0.3
6.0
V
LFILT+ Current
I
VDREG
-
10
μ
A
Inputs
Input Current
I
in
-
±10
mA
Temperature
Ambient Operating Temperature (power applied)
T
A
-20
+125
°C
Storage Temperature
T
stg
-65
+150
°C
