CRD1680-7W
18 DS1017RD3
8. PERFORMANCE PLOTS (120VAC)
0
0.1
0.2
0.3
0.4
0.5
20 40 60 80 100 120 140 160 180
Output Cur
rent
(A
)
Dim Angle ( o )
Mode 1
Mode 1 - Hatch LS1250EN w/Leading-edge Waveform
Mode 2 - Lightech LET60 w/
Traili ng-edge Waveform
Mode 3 - Lightech LET60 w/Leading-edge Waveform
Mode 3
Mode 2 Mode 1
Mode 3
Mode 2
Figure 12. Typical CRD1680-7W Output Current vs. Dim Angle, 120VAC
0
2
4
6
8
10
12
20 40 60 80 100 120 140 160 180
Input Pow
e
r (W
)
Dim Angle ( o )
Mode 1 - Hatch LS1250EN w/Leading-edge Waveform
Mode 2 - Lightech LET60 w/Trailing-edge Waveform
Mode 3 - Lightech LET60 w/Leading-edge Waveform
Mode 1
Mode 3
Mode 2
Figure 13. Typical CRD1680-7W Input Power vs. Dim Angle, 120VAC
