dimmer switch on the falling edge of the input voltage using a
source-controlled dimmer-compatibility circuit.
5.3.2 Switch Overpower Protection
To prevent excessive power dissipation on the source-switched
FET Q2, the CS1615A/16A monitors voltage across FET Q2 and
current flow through FET Q2 to calculate average power
dissipation. If the calculated power exceeds the overpower
protection threshold, a fault condition occurs. The IC output is
disabled and the controller attempts to restart after
approximately thirty seconds.
5.4 Voltage Clamp Circuit
To keep trailing-edge dimmer switches conducting and from
misfiring, the dimmer switch internal capacitor has to be
charged quickly around the trailing edge of the phase-cut
waveform. In addition to the dimmer compatible circuit, an
optional clamp circuit provides a high-current sinking path for
delivering the required amount of charge onto the dimmer
switch capacitor in a short amount of time.
The CS1615A/16A provides active clamp circuitry on the
CLAMP pin, as shown in Figure 12.
5.4.1 Clamp Overpower Protection
The CS1615A/16A clamp overpower protection (COP) control
logic averages the turn-on time of the clamp circuit. If the output
of the averaging logic exceeds 10%, a COP event is actuated.
The clamp circuit is disabled as well as the flyback/buck-boost
controller and the dimmer-compatibility circuit. The COP fault
state is not cleared until the power to the IC is recycled.
5.5 Dimmer Angle Extraction and the Dim
Mapping Algorithm
When operating with a dimmer, the dimming signal is extracted
in the time domain and is proportional to the conduction angle of
the dimmer. A control variable is passed to the quasi-resonant
flyback/buck-boost controller to achieve a wide range of output
currents.
5.6 Dual-mode Flyback/Buck-boost
The CS1615A/16A is configurable for isolated or non-isolated
topologies using a flyback transformer or buck-boost inductor,
respectively. The CS1615A/16A controls the dual-mode
flyback/buck-boost to satisfy the dimmer hold current
requirement in Dimmer Mode and provide power factor
correction in No-dimmer Mode. The dual-mode ensures a
minimum average input current greater than the required dimmer
hold current when behind a dimmer and shapes the line current
when not behind a dimmer to provide power factor correction. It
also ensures half line-cycle averaged constant output current.
Figure 13 illustrates the dual-mode flyback topology. The
CS1615A/16A regulates output current using primary-side
control, which eliminates the need for opto-coupler feedback.
The control loop operates in peak current control mode.
Demagnetization time of the transformer is sensed by the
FBAUX pin using an auxiliary winding and is used as an input to
the control loop.
