Order address

Address set up on the scale, by default 1.

Scale symbol

The scale symbol on the scale overlay, required
among others in the CPG system.

Serial number

The scale serial number.

Parametres
descriptions

The box for the scale parametres: Max, Min, d, e.
Required among others in the CPG system.

Connection name

A name of communication interface.

Connection type

Selection of interface type connected with the scale:
Serial – scale connected by RS232,
Ethernet – scale connected by Ethernet.

IP address

IP address set up in Ethernet interface on the scale,

TCP port

TCP port set up on the scale
(by default 4001)


Save the changes pressing

button, or exit the box without saving

the changes pressing

button.



2.2.2.1.2 Scale edition

In the configuration box select the scale
whose parametres you would like to

configure and press

button.

35
