Using Edit button, activate the box in which you can set up the
communication interface parametres with the scale.
The interface settings:
Connection type
Connection type (None – without the
connection, Serial – the scale connected by
RS232, Ethernet – the scale connected by
Ethernet)
Connection String
The connection shortened address,
configuration
Host/IP
IP address set up for the scale (for
connection like Ethernet),
Port
TCP Port set up for the scale
(by default 4001)
Baud rate
Baud rate RS232 (by default for moisture
analyzer 9600 bps, for WPW, WLY, WPY,
HTY scales set up 115200 bps)
Data bits
Data bits (by default DB_8)
Handshake
Protocol control for recognizing
communication (by default None)
Parity
Parity control (by default None)
Port name
Computer port number
COM1, COM2, ...
Stop bits
Stop bits (by default One)
