Commissioning, operation, Connection diagram for output 4 ma (standard) – WIKA A2G-70 User Manual
Page 10
WIKA operating instructions air2guide model A2G-70
GB
10
40202801.03 08/2012 GB/D/F/E/I
DR
W_TH0.04a
Out Temp 0-10V
Out RH 0-10V
UB 15-24V=/ 24V~
Gnd
Temp. sensor
(option)
Load
Load
Connection diagram for output 4 ... 20 mA (standard)
6. Commissioning, operation
Electrical connection
Connection diagram
The instruments are designed to operate with safety extra-low voltage
(SELV). The transmitters must be operated at a constant operating
voltage (±0.2 V). Current/voltage spikes from switching the power
supply on or off must be prevented by the customer.
