WIKA operating instructions air2guide model A2G-60
GB
8
40202798.02 08/2012 GB/D/F/E/I
4. Design and function
4.1 Description
Design
CE conformity:
2004/108/EG Electromagnetic compatibility (EMC)
2002/95/EC RoHS (restriction of the use of certain hazardous
substances in electrical and electronic equipment)
Accuracy @ 21°C
Typically ±1 % of measuring range
Scale ranges
Standard temperature setting: 0 … +50 °C
to be set via jumper: -50 … +50 °C, -15 … +35 °C, -10 … +120 °C,
0 … +160 °C, 0 … +250 °C
Permissible temperature
■ Head temperature
-35 … +90 °C passive (Pt1000 and Ni1000)
-35 … +70 °C active (TRV and TRA)
■ Sensor sleeve
Standard: -50 … +160 °C
High temperature version: -50 ... + 260 °C
4.2 Scope of delivery
Cross-check the scope of delivery with the delivery note.
4. Design and function
