Diagnostics
3 Basic adjustment
Display
▶ Diagnostics
Service
Info
3.1 Pointer
p-min.: -5.8 mbar
p-max.: 167.5 mbar
T-min.: -12.5 °C
T-max.: +85.5 °C 3.2 Sensor status
OK
3.3.1 Trend curve
Start trend curve?
Service
4 Basic adjustment
Display
Diagnostics
▶ Service
Info
4.1 Current output
Output mode: 4-20 mA ▼
Fail.mode: < 3.6 mA ▼
Min. current: 3.8 mA ▼
max. current: 20.5 mA ▼
4.2 Simulation
Start simulation ▼
4.3 Reset
Select reset ▼
4.4 Language
Deutsch ▼
4.5 SIL
Deactivated! ▼
4.6 HART mode
Standard
Address 0
4.7 Copy sensor data
Copy sensor data?
4.8 PIN
Enable?
4.9 Application
Level ▼
Info
5 Basic adjustment
Display
Diagnostics
Service
▶ Info
5.1 Sensor type
Serial number
12345678
5.2 Date of manufacture
e.g. 16. May 2008
Software version
e.g. 3.50 5.3 Last change using PC
e.g. 16. May 2008
5.4 Sensor characteristics
Display now?
24 Indicating and adjustment module for IPT-1* sensors
5 Set up
